Product Description
Specification :
| Capacity | Machine Screw: M4 – M8 (5/32″ – 5/16″) Standard Bolt: M5 – M14 (3/16″ – 9/16″) High Tensile Bolt: M5 – M12 (3/16″ – 1/2″) Coarse Thread (in length): 22 – 90 mm (7/8″ – 3-1/2″) |
| Hex Shank | 6.35 mm (1/4″) |
| Impacts Per Minute (IPM) | Hard: 0 – 3,900 | Soft: 0 – 1,600 |
| Max Fastening Torque | 140 N·m (1,240 in.lbs.) |
| No Load Speed (RPM) | Hard: 0 – 3,000 | Soft: 0 – 1,300 |
| Dimensions (L x W x H) | 135 x 79 x 232 mm (5-5/16″ x 3-1/8″ x 9-1/8″) |
| Net Weight | 1.2 – 1.5 kg (2.6 – 3.3 lbs.) |
| Work Amount (approx.) | 725 pcs with BL1850B Coarse Thread Screw 65 mm (Melapi) |
